Name: PIR Motion Sensor for Alarm Hub, 12m Range & Pet Immune
Brand: VIMEL
SKU: VIM-PIRS
Price: 39.0 NZD
Availability: InStock

PIR Motion Sensor for Alarm Hub, 12m Range & Pet Immune

$39.00 NZD

Quantity

Key Specs

Detection Type

Passive infrared body heat

Detection Range

12 m at 90 degrees

Pet Immunity

Ignores animals under 25 kg

Battery

CR123A, about one year

Wireless Range

Up to 150 m to the hub

Tamper Protection

Alarms if removed or opened

Estimated delivery 10 to 11 November Delivery Info Pay Options

Express Shipping, 2 to 3 Business Days

Safe and Secure Transaction

Tracked and Signed For

Discreet Packing and Delivery
Hassle-Free Warranty
Support From Real Specialists

Have a Question? Chat Now or Call Us

Description

You are asleep upstairs. Downstairs, a window slides open. Did someone just come in?

The VIM-PIRS motion sensor watches for body heat rather than movement alone, so a curtain in a draught does not wake the house but a person walking through the room does. It covers 12 metres at 90 degrees, ignores animals under 25 kg, reports to your VIM-4GALARM hub on 433MHz from up to 150 metres away, and runs about a year on one CR123A cell.

Features

Spot Intruders by Body Heat: Body heat detection identifies human heat signatures within 12 metres, ignoring ambient temperature changes and false triggers
Know When Anything Moves: Motion sensor covers a 12m x 12m area with a 90° detection angle, catching movement from any direction
Prevent Tampering: Built-in tamper protection triggers alarm if sensor is touched or removed
Live With Pets in Peace: Pet immunity ignores animals under 25kg, preventing false alarms from dogs and cats
Months Between Battery Changes: Sleep mode activates between detections, conserving CR123A battery for extended operation
Hear What's Happening: Two-way audio lets you listen to activity and speak through the sensor
Setup in Minutes: Fast smartphone pairing connects to VIM-4GALARM system instantly via 2.4GHz WiFi

Applications

Real-World Scenarios

The Empty House During the Day

You are at work and nobody should be inside. Any movement in the living room is a problem.

Mount the sensor in a corner facing the room's main walkway rather than at a window. Thermal detection picks up a person crossing the 12 metre range, the hub alerts your phone, and the family dog underneath the coffee table does not.

The Hallway Overnight

The children are asleep upstairs and you want the downstairs covered without the alarm going off every time the cat moves.

Place the sensor at the foot of the stairs looking along the hallway. Pet immunity up to 25 kg keeps it quiet, and tamper protection means anyone who tries to lift it off the wall triggers the alarm instead of disabling it.

A Holiday Home Left Standing Empty

A bach that sits unused for months needs cover that does not need a power point or a service call.

Sleep mode between detections stretches the CR123A cell to roughly a year, and the 150 metre wireless range reaches a hub anywhere in a normal house, so you can put the sensor in an outbuilding or a far bedroom.

How it Works

Mount the sensor with the magnetic bracket or the supplied tape, two metres or so up, angled across the room rather than at a window or heater.
Pair it to your VIM-4GALARM hub from the app. It reports in every two hours so you know it is still alive.
When body heat crosses the 12 metre detection zone, the sensor signals the hub on 433MHz and the hub pushes an alert to your phone over WiFi or its 4G SIM.

Specifications

Model: VIM-PIRS
Detection Technology: Passive Infrared (PIR), body heat sensing
Detection Range: 12 metres maximum
Detection Angle: 90 degrees
Coverage Area: 12m x 12m x 2.5m height
Wireless Range: 150 metres to central hub
Wireless Frequency: 433MHz (sensor to hub)
WiFi Frequency: 2.4GHz (hub to network)
Pet Immunity: Up to 25kg animal weight
Battery Type: CR123A Lithium 3V
Working Current: 35mA (active)
Standby Current: 20μA (sleep mode)
Heartbeat Report: Every 2 hours
Operating Temperature: 10°C to 60°C
Storage Temperature: -10°C to 60°C
Dimensions: 70mm (L) x 50mm (W) x 35mm (D)

Frequently Asked Questions

Does this work without the VIM-4GALARM hub?

No. It is a sensor for that system and has no siren or network connection of its own. It needs the hub to raise an alarm and to reach your phone.

Will my pets set it off?

Not under 25 kg. Cats and small to medium dogs are ignored. A larger dog can still register, so mount the sensor higher and angle it across the room rather than down toward the floor.

How long does the battery last?

About a year on the CR123A cell in normal use, because the sensor sleeps between detections.

How many of these can I run on one hub?

Up to 32 sensors on the VIM-4GALARM system, which covers a large house comfortably.

What happens if someone tries to pull it off the wall?

Tamper protection triggers the alarm immediately if the housing is opened or the sensor is removed from its bracket.

Can I use this to monitor a flatmate or a tenant?

It detects movement and does not record video or audio, so it is a security sensor rather than a surveillance device. You can protect any space you have the right to secure. If you are a landlord, sensors inside a tenanted property need the tenant's agreement, and anything that records people brings the Privacy Act 2020 into it.
