Central Hub
The central hub is the heart of this home alarm system, integrating advanced connectivity and management features to ensure seamless security. It operates on a wireless network with a frequency of FSK 433MHz, and supports WIFI at 2.4GHz using the IEEE802.11b/g/n protocol. This setup allows for robust and stable connectivity within a range of up to 100 meters. The central hub also includes a 4G module that supports various SIM cards, including Telstra, Aldi, Woolworths, Belong, TPG, Optus, and Vodafone. This versatility ensures that you can maintain reliable communication with the system, even if your primary internet connection fails. Additionally, the central hub can manage up to 96 wireless devices, making it highly scalable for expanding your home security system. It features a loud siren with an 80dB sound level to alert you of any breaches, and it operates within a temperature range of -10°C to 60°C. The power supply is versatile, using a 3.7V power adapter and a rechargeable 3000mAH battery, ensuring continuous operation and reliability.
Window / Door Sensor
The window and door sensors are crucial components of this security system, designed to provide comprehensive coverage of entry points. These sensors operate on a wireless frequency of 433MHz and can transmit signals up to 150 meters. They are powered by a 3V lithium battery and are built to detect any unauthorized opening of windows or doors. The sensors feature an alarm current of 150mA and a standby current of 35mA, with a static current of only 10uA, ensuring long-lasting battery life. The compact design of the sensors includes dimensions of 69.5mm (L) x 21.2mm (W) x 19.5mm (H) for the sensor unit, and 34.5mm (L) x 10mm (W) x 13.2mm (H) for the probe, making them easy to install discreetly on doors and windows.
PIR Sensor
The PIR sensor is an essential element of this alarm system, designed to detect motion and thermal changes with high accuracy. It operates on a wireless frequency of 433MHz and has a WIFI frequency of 2.4GHz. The sensor covers an area of up to 12 meters in distance and 90° in angle, making it effective for monitoring large spaces. It can detect movement in an area of 12m x 12m with a height coverage of 2.5 meters. The sensor's power supply is a CR123A lithium battery, providing 3V of power. It features a working current of 35mA and a quiescent current of just 20uA, ensuring efficient operation. With pet immunity for animals up to 25kg, it prevents false alarms caused by small pets. The sensor also provides heat-beat reports every two hours, and it functions well within an operating temperature range of 10°C to 60°C. The dimensions of the PIR sensor are 70mm (L) x 50mm (W) x 35mm (D), making it compact and easy to position in your home.
This wireless 4G alarm home security system integrates a range of advanced features to deliver a comprehensive and reliable security solution for your home. With the ability to connect multiple devices, maintain communication through various networks, and monitor your home remotely, it provides robust protection tailored to meet your needs. The detailed specifications of each component ensure that the system operates efficiently and effectively, giving you confidence in the security of your home.
DIY Installation - Easy Installation
The home alarm systems are designed for easy DIY installation, making it accessible for anyone to set up. You don't need professional help to get started with this alarm security system. Clear instructions guide you through the process, allowing you to install and configure the system quickly and efficiently.
Dual Network Support - 4G + WIFI
This house alarm system supports dual network connections via 4G and WIFI, providing robust and uninterrupted security. The dual network ensures that even if one connection fails, the other can seamlessly take over, maintaining the reliability of your home security alarm system.
ONVIF Support - Connect Other Cameras to the System
With ONVIF support, you can connect additional security cameras to your system. This feature enhances your home security alarm systems by integrating multiple cameras, allowing for comprehensive coverage and monitoring of your property.
Direct Router Connection - Ethernet Cable
For those who prefer a wired connection, this alarm system for home offers direct router connectivity via an Ethernet cable. This option ensures a stable and high-speed connection, crucial for uninterrupted security monitoring and alert notifications.
Install SIM Card to Access 4G Network
By installing a SIM card, you can access the 4G network, providing a reliable alternative to WIFI. This feature is particularly useful in areas with weak WIFI signals, ensuring that your home alarm systems remain functional at all times.
Access Remotely From Anywhere and Anytime
One of the standout features of this alarm system for homes is the ability to access it remotely. Whether you're at work or on vacation, you can monitor and control your home alarm system through your smartphone, providing peace of mind and control over your home security.
4G+WIFI System Alert Messages During Power Cuts
Unlike traditional WIFI systems, this 4G+WIFI home security alarm system can send alert messages even during power outages. This ensures that you are always informed about the security status of your home, regardless of the power situation.
Alarm Trigger - SIM Relays Images to the Cloud
When an alarm is triggered, the system can relay images to the cloud from up to four cameras, even if the internet connection is disabled. This feature ensures that crucial data is never lost, providing a reliable backup for your home security alarm systems.
Connect Remotely and Monitor LIVE using Your Mobile Phone
The ability to connect remotely and monitor live footage from your mobile phone enhances the functionality of this home alarm system. You can view real-time updates and respond to any security alerts instantly, no matter where you are.
Receive Alarm Notifications Directly to Your Smart Phone
Stay informed with alarm notifications sent directly to your smartphone. This feature ensures that you are always aware of any security breaches or issues, allowing you to take immediate action to protect your home.
Operate and Modify the Alarm System using Application (Android / iOS)
The dedicated mobile application for Android and iOS allows you to operate and modify your alarm system with ease. You can customize settings, arm or disarm the system, and access a range of features from your phone, making home security management simple and convenient.
Loud Siren - Two Ways of Audio Communication (Speaker + Microphone)
The alarm system includes a loud siren and supports two-way audio communication. This means you can not only scare off intruders with a loud alarm but also communicate with them through the built-in speaker and microphone, enhancing your home security measures.
Wall Mount Support
For optimal placement, the alarm system comes with wall mount support. This allows you to install the central hub and sensors in strategic locations around your home, ensuring maximum coverage and effectiveness of your home alarm systems.
Backup Rechargeable Batteries in Case of Power Outage
In the event of a power outage, the backup rechargeable batteries ensure that your alarm system continues to operate. This feature guarantees that your home remains protected at all times, regardless of power availability.
Important Accessories
This product offers optional accessories that can expand your security system, including a wireless smoke detector, wireless window and door sensors, wireless security cameras, and a wireless PIR sensor. These additional components enhance the overall functionality and effectiveness of your home security alarm systems, providing comprehensive protection for your property.
The wireless 4G alarm home security system combines advanced technology, user-friendly features, and robust security measures to offer a comprehensive solution for protecting your home. Its wireless nature simplifies installation and connectivity, while dual network support and remote access provide reliability and convenience. This alarm system for homes ensures that you are always informed and in control, making it an essential addition to any home security setup.
